SAFARI DIAMOND
DRILL BItS

We conecentrate on producing the best impregnated diamond bits and reaming shells. Safari makes nothing else. Our focus is your satisfaction with these well designed, field tested products. That's all we care about. You'll find our experienced production team delivers exactly what you need - any time, anywhere. Count on it.

VIEW PRODUCTS
drill

Choose the one that will give you the best results:

The harder the ground you're working, the softer the matrix you'll need - and Safari makes it easy to make a matrix match. So
a higher number on our scale indicates a softer matrix for tougher driller conditions.

Detail Of A-Gauge Core Bits

SPECIFICATIONS

Bit Size Outside Set Diameter Inside Set Diameter
inch mm inch mm
aWL 1.880 / 1.870   47.75 / 47.50 1.067 / 1.057   27.10 / 26.85
aWL-RSG 1.895 / 1.885   48.13 / 47.88 1.067 / 1.057   27.10 / 26.85
atw 1.880 / 1.870    47.75 / 47.50 1.190 / 1.180   30.22 / 29.97
agm 1.880 / 1.870    47.75 / 47.50 1.198 / 1.188    30.43 / 30.18
aWLtk 1.880 / 1.870    47.75 / 47.50 1.206 / 1.196    30.63 / 30.38
aWT (AXT) 1.880 / 1.870    47.75 / 47.50 1.286 / 1.276    32.66 / 32.41
aTK-34 (AW34) 1.880 / 1.870    47.75 / 47.50 1.325 / 1.315    33.65 / 33.40
IAw, IAws 1.880 / 1.870    47.75 / 47.50 1.394 / 1.384    35.40 / 35.15
lTK48, JTK48 1.880 / 1.870    47.75 / 47.50 1.394 / 1.384    35.40 / 35.15

hARDNESS TABLE

hardness

waTERWay

You achieve more efficient penetration with Safari's comprehensive selection of waterway configurations. Choose the one that best suits your needs - for better bit hydraulics to control how much of the Safari bit face contacts the rock surface. Configurations shown here are available for most of our bit crowns.

standerd
standerd
standerd
standerd
standerd
standerd
1

Extended Waterway Flushing

For competent and semi-broken rock
Functions well in mixed formation

Wedge Type (pie-shaped)

For competent and semi-broken rock
Functions well in mixed formations

2

3-Vee Design

For hard and competent formations
A free cutting bit for high productivity

3

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Turbo Waterway

For competent formations
Offers high productivity

4

Turbo Waterway

For competent formations
Offers high productivity

4

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Detail Of B-Gauge Core Bits

SPECIFICATIONS

Bit Size Outside Set Diameter Inside Set Diameter
inch mm inch mm
BWL 2.350 / 2.340   59.69 / 59.44 1.438 / 1.428   36.52 / 36.27
BWL-RSG 2.365 / 2.355   60.07 / 59.82 1.438 / 1.428   36.52 / 36.27
BWL-2.400 2.405 / 2.395    61.09 / 60.83 1.438 / 1.428   36.52 / 36.27
BXB (BWC3) 2.365 / 2.355    60.07 / 59.82 1.438 / 1.428    36.52 / 36.27
BWL3 2.350 / 2.340    59.69 / 59.44 1.325 / 1.315    33.65 / 33.40
BWLTK 2.350 / 2.340    59.69 / 59.44 1.606 / 1.596    40.79 / 40.54
BGM (BTW) 2.350 / 2.340    59.69 / 59.44 1.659 / 1.649    42.13 / 41.88
BWG, BWM, BX 2.350 / 2.340    59.69 / 59.44 1.660 / 1.650    42.16 / 41.91
LTK60 2.350 / 2.340    59.69 / 59.44 1.742 / 1.732    44.25 / 44.00
BWT 2.350 / 2.340    59.69 / 59.44 1.755 / 1.745    44.58 / 44.32
BW44 2.405 / 2.395    61.09 / 60.83 1.760 / 1.750    44.70 / 44.45
TBW 2.350 / 2.340    59.69 / 59.44 1.785 / 1.775    45.34 / 45.09

hARDNESS TABLE

hardness

waTERWay

You achieve more efficient penetration with Safari's comprehensive selection of waterway configurations. Choose the one that best suits your needs - for better bit hydraulics to control how much of the Safari bit face contacts the rock surface. Configurations shown here are available for most of our bit crowns.

standerd
standerd
standerd
standerd
standerd
standerd
1

Extended Waterway Flushing

For competent and semi-broken rock
Functions well in mixed formation

Wedge Type (pie-shaped)

For competent and semi-broken rock
Functions well in mixed formations

2

3-Vee Design

For hard and competent formations
A free cutting bit for high productivity

3

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Turbo Waterway

For competent formations
Offers high productivity

4

Turbo Waterway

For competent formations
Offers high productivity

4

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Detail Of N-Gauge Core Bits

SPECIFICATIONS

Bit Size Outside Set Diameter Inside Set Diameter
inch mm inch mm
NWL 2.970 / 2.960   75.44 / 75.19 1.880 / 1.870   47.75 / 47.50
NWL-RSG 2.985 / 2.975   75.82 / 75.57 1.880 / 1.870   47.75 / 47.50
NWL-3.032 3.037 / 3.027    77.14 / 76.89 1.880 / 1.870   47.75 / 47.50
NWL2 2.970 / 2.960    75.44 / 75.19 2.000 / 1.990    50.80 / 50.55
NWL2-RSG 2.985 / 2.975    75.82 / 75.57 2.000 / 1.990    50.80 / 50.55
NWL2-3.032 3.037 / 3.027    77.14 / 76.89 2.000 / 1.990    50.80 / 50.55
NWL3 (NWLTT) 2.970 / 2.960    75.44 / 75.19 1.780 / 1.770    45.21 / 44.96
NWL3-RSG 2.985 / 2.975    75.82 / 75.57 1.780 / 1.770    45.21 / 44.96
NWL3-3.032 3.037 / 3.027    77.14 / 76.89 1.780 / 1.770    45.21 / 44.96
CHD76 2.985 / 2.975    75.82 / 75.57 1.717 / 1.707    43.61 / 43.36
NGR 2.970 / 2.960    75.44 / 75.19 1.742 / 1.732    44.25 / 44.00
NXB (NWC3) 2.985 / 2.975    75.82 / 75.57 1.880 / 1.870    47.75 / 47.50
NXB-3.032) 3.037 / 3.027    77.14 / 76.89 1.880 / 1.870    47.75 / 47.50
NMLC 2.970 / 2.960    75.44 / 75.19 2.052 / 2.042    52.12 / 51.87
NWD4 2.985 / 2.975    75.82 / 75.57 2.065 / 2.055    52.45 / 52.20
NWD4-3.032 3.037 / 3.027    77.14 / 76.89 2.065 / 2.055    52.45 / 52.20
NWG, NWM, NX) 2.970 / 2.960    75.44 / 75.19 2.160 / 2.150    54.86 / 54.61
NGM (NTW) 2.970 / 2.960    75.44 / 75.19 2.214 / 2.204    56.23 / 55.98
NWT 2.970 / 2.960    75.44 / 75.19 2.318 / 2.308    58.87 / 58.62
TNW 2.970 / 2.960    75.44 / 75.19 2.394 / 2.384    60.80 / 60.55

hARDNESS TABLE

hardness

waTERWay

You achieve more efficient penetration with Safari's comprehensive selection of waterway configurations. Choose the one that best suits your needs - for better bit hydraulics to control how much of the Safari bit face contacts the rock surface. Configurations shown here are available for most of our bit crowns.

standerd
standerd
standerd
standerd
standerd
standerd
1

Extended Waterway Flushing

For competent and semi-broken rock
Functions well in mixed formation

Wedge Type (pie-shaped)

For competent and semi-broken rock
Functions well in mixed formations

2

3-Vee Design

For hard and competent formations
A free cutting bit for high productivity

3

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Turbo Waterway

For competent formations
Offers high productivity

4

Turbo Waterway

For competent formations
Offers high productivity

4

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Detail Of H-Gauge Core Bits

SPECIFICATIONS

Bit Size Outside Set Diameter Inside Set Diameter
inch mm inch mm
HWL 3.770 / 3.755   95.76 / 95.38 2.505 / 2.495   63.63 / 63.38
HWL-RSG 3.790 / 3.775   96.27 / 95.89 2.505 / 2.495   63.63 / 63.38
HWL-3.830 3.840 / 3.825    97.54 / 97.16 2.505 / 2.495   63.63 / 63.38
HWL-3.895 3.897 / 3.882    98.98 / 98.60 2.505 / 2.495    63.63 / 63.38
HWL3 (HWLTT) 3.770 / 3.755    95.76 / 95.38 2.411 / 2.401    61.24 / 60.99
HWL3-RSG 3.790 / 3.775    96.27 / 95.89 2.411 / 2.401    61.24 / 60.99
HWL3-3.830) 3.840 / 3.825    97.54 / 97.16 2.411 / 2.401    61.24 / 60.99
HWL3-3.895 3.897 / 3.882    98.98 / 98.60 2.411 / 2.401    61.24 / 60.99
CHD101 3.975 / 3.960    100.96 / 100.58 2.505 / 2.495    63.63 / 63.38
HXB (HWD3) 3.655 / 3.645    92.83 / 92.58 2.405 / 2.395    61.09 / 60.84
HXB-3.750 3.755 / 3.745    95.38 / 95.13 2.405 / 2.395    61.09 / 60.84
HWD4 3.655 / 3.645    92.83 / 92.58 2.411 / 2.401    61.24 / 60.99
HWD4-3.750 3.755 / 3.745    95.38 / 95.13 2.411 / 2.401    61.24 / 60.99
HMLC 3.897 / 3.882    98.98 / 98.60 2.505 / 2.495    63.63 / 63.38
HTW 3.770 / 3.755    95.76 / 95.38 2.797 / 2.787    71.04 / 70.79

hARDNESS TABLE

hardness

waTERWay

You achieve more efficient penetration with Safari's comprehensive selection of waterway configurations. Choose the one that best suits your needs - for better bit hydraulics to control how much of the Safari bit face contacts the rock surface. Configurations shown here are available for most of our bit crowns.

standerd
standerd
standerd
standerd
standerd
standerd
1

Extended Waterway Flushing

For competent and semi-broken rock
Functions well in mixed formation

Wedge Type (pie-shaped)

For competent and semi-broken rock
Functions well in mixed formations

2

3-Vee Design

For hard and competent formations
A free cutting bit for high productivity

3

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Turbo Waterway

For competent formations
Offers high productivity

4

Turbo Waterway

For competent formations
Offers high productivity

4

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Detail Of P-Gauge Core Bits

SPECIFICATIONS

Bit Size Outside Set Diameter Inside Set Diameter
inch mm inch mm
PWL 4.815 / 4.795   122.30 / 121.80 3.350 / 3.340   85.09 / 84.84
PWL3 4.815 / 4.795   122.30 / 121.80 3.275 / 3.265   83.18 / 82.93

hARDNESS TABLE

hardness

waTERWay

You achieve more efficient penetration with Safari's comprehensive selection of waterway configurations. Choose the one that best suits your needs - for better bit hydraulics to control how much of the Safari bit face contacts the rock surface. Configurations shown here are available for most of our bit crowns.

standerd
standerd
standerd
standerd
standerd
standerd
1

Extended Waterway Flushing

For competent and semi-broken rock
Functions well in mixed formation

Wedge Type (pie-shaped)

For competent and semi-broken rock
Functions well in mixed formations

2

3-Vee Design

For hard and competent formations
A free cutting bit for high productivity

3

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Turbo Waterway

For competent formations
Offers high productivity

4

Turbo Waterway

For competent formations
Offers high productivity

4

Face-Flushing Waterway

For broken/granular formations
Minimizes flishing of the core sample

5

Standard Waterway Flushing

For a broad range of formations
A solid general purpose design

6

Detail Of Reaming Shells

Standard Features

  • Full-matrix body gauge ring cast onto a steel-tool body for maximum strength and tool integrity
  • Spiral waterway canals that clear bit cuttings effectively, while maintaining full 360-hole contact with the matrix body gauge ring
  • Gauge ring setting combining a mechanically-rounded P3 Grade natural drill diamond of 20 to 35 stones per carat with seismic-grade, tungsten-carbide wear pads cast to be tough and abrasion-resistant

Available Options

  • Hard metal strips armour-coating the steel tool body
  • Synthetic material replacing the natural P3 grade diamond if potential contamination by natural diamond crystals is a concern.

Detail Of Casing Shoes

SPECIFICATIONS

Bit Size Outside Set Diameter Inside Set Diameter
inch                       mm inch                       mm
AW* 2.350/2.340   59.69/59.44 1.902/1.897   43.31/48.18
BW 2.970/2.960   75.44/75.19 2.377/2.367   60.38/60.12
NW* 3.620/3.610   91.95/ 91.70 2.997/2.987   76.12/75.87
HW** 4.632/4.617   117.65/117.27 3.930/3.920   99.82/99.57
HWT 4.632/4.617   117.65/117.27 3.930/3.920   99.82/99.57
PW* 5.660 / 5.640   143.76/143.26 4.865/4.850   123.57/123.19

Bits test result application

BECOME A DISTRIBUTor

Safari Has Been A Leading Canadian Manufacturer Specializing In These Critical Mineral Exploration Tools In Business To Since 2006.

Quick Links
Products
Accessories
Quick Contact
4185 McConnell Dr
Burnaby,BC V5A 3J7
Canada
1-888-500 BITS (2487)

© 2018 Safari Diamond Bits Ltd. All Rights Reserved
